package com.example.image_zoomin_zoomout;
import android.os.Bundle;
import android.app.Activity;
import android.graphics.Matrix;
import android.graphics.PointF;
import android.util.FloatMath;
import android.util.Log;
import android.view.Menu;
import android.view.MotionEvent;
import android.view.View;
import android.view.View.OnTouchListener;
import android.widget.ImageView;
public class MainActivity extends Activity implements OnTouchListener{
/**Variables Declaration*/
private static final String TAG = "Touch";
@SuppressWarnings("unused")
private static final float MIN_ZOOM = 1f,MAX_ZOOM = 1f;
// These matrices will be used to scale points of the image
Matrix matrix = new Matrix();
Matrix savedMatrix = new Matrix();
// The 3 states (events) which the user is trying to perform
static final int NONE = 0;
static final int DRAG = 1;
static final int ZOOM = 2;
int mode = NONE;
// these PointF objects are used to record the point(s) the user is touching
PointF start = new PointF();
PointF mid = new PointF();
float oldDist = 1f;
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
ImageView imv = (ImageView)findViewById(R.id.imageView1);
imv.setOnTouchListener(this);
}
public boolean onTouch(View v, MotionEvent event)
{
ImageView imv = (ImageView) v ;
imv.setScaleType(ImageView.ScaleType.MATRIX);
float scale;
dumpEvent(event);
switch (event.getAction() & MotionEvent.ACTION_MASK) {
case MotionEvent.ACTION_DOWN:
savedMatrix.set(matrix);
start.set(event.getX(), event.getY());
Log.d(TAG,"Mode =Drage");
mode = DRAG;
break;
case MotionEvent.ACTION_UP:
case MotionEvent.ACTION_POINTER_UP:
mode =NONE;
Log.d(TAG, "Mode = None");
break;
case MotionEvent.ACTION_POINTER_DOWN:
oldDist = spacing(event);
Log.d(TAG, "oldDist=" + oldDist);
if(oldDist > 10f)
{
savedMatrix.set(matrix);
midPoint(mid, event);
mode = ZOOM;
Log.d(TAG, "mode=ZOOM");
}
break;
case MotionEvent.ACTION_MOVE:
if (mode == DRAG)
{
matrix.set(savedMatrix);
matrix.postTranslate(event.getX() - start.x, event.getY() - start.y);
}
else if (mode == ZOOM)
{
float newDist = spacing (event);
Log.d(TAG, "newDistance=" +newDist);
if (newDist > 5f)
{
matrix.set(savedMatrix);
scale = newDist / oldDist;
// setting the scaling of the matrix...if scale > 1 means zoom in...if scale < 1 means zoom out
matrix.postScale(scale, scale, mid.x, mid.y);
}
}
break;
}
imv.setImageMatrix(matrix);
return true;
}
/*
* --------------------------------------------------------------------------
* Method: spacing Parameters: MotionEvent Returns: float Description:
* checks the spacing between the two fingers on touch
* ----------------------------------------------------
*/
private float spacing(MotionEvent event) {
// TODO Auto-generated method stub
float x = event.getX(0) - event.getX(1);
float y = event.getY(0) - event.getY(1);
return FloatMath.sqrt(x * x + y *y);
}
/*
* --------------------------------------------------------------------------
* Method: midPoint Parameters: PointF object, MotionEvent Returns: void
* Description: calculates the midpoint between the two fingers
* ------------------------------------------------------------
*/
private void midPoint(PointF point, MotionEvent event) {
// TODO Auto-generated method stub
float x = event.getX(0) + event.getX(1);
float y = event.getY(0) + event.getY(1);
point.set(x/2, y/2);
}
/** Show an event in the LogCat view, for debugging */
private void dumpEvent(MotionEvent event) {
// TODO Auto-generated method stub
String names[] = {"DOWN", "UP", "MOVE", "CANCEL", "OUTSIDE","POINTER_DOWN", "POINTER_UP", "7?", "8?", "9?" };
StringBuilder sb = new StringBuilder();
int action = event.getAction();
int actionCode = action & MotionEvent.ACTION_MASK;
sb.append("event ACTION_").append(names[actionCode]);
if (actionCode == MotionEvent.ACTION_POINTER_DOWN || actionCode == MotionEvent.ACTION_POINTER_UP)
{
sb.append("(paid").append(action >> MotionEvent.ACTION_POINTER_ID_SHIFT);
sb.append(")");
}
sb.append("[");
for (int i = 0; i < event.getPointerCount(); i++)
{
sb.append("#").append(i);
sb.append("(pid ").append(event.getPointerId(i));
sb.append(")=").append((int) event.getX(i));
sb.append(",").append((int) event.getY(i));
if (i + 1 < event.getPointerCount())
sb.append(";");
}
sb.append("]");
Log.d("Touch Events ---------", sb.toString());
}
@Override
public boolean onCreateOptionsMenu(Menu menu) {
// Inflate the menu; this adds items to the action bar if it is present.
getMenuInflater().inflate(R.menu.activity_main, menu);
return true;
}
}
Layout : activity_main.xml
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
xmlns:tools="http://schemas.android.com/tools"
android:layout_width="match_parent"
android:layout_height="wrap_content"
android:orientation="vertical" >
<ImageView
android:id="@+id/imageView1"
android:layout_width="fill_parent"
android:layout_height="422dp"
android:src="@drawable/android" />
</LinearLayout>
